Growatt Off-Grid Storage Inverter  single phase 4/5/6 kw -Koodsun

Growatt Off-Grid Storage Inverter single phase 4/5/6 kw

SPF 4KT HVM

SPF 5KT HVM

SPF 6KT HVM

Place of Origin
Anhui, China



Brand Name
DAH



Model Number
SPF 4~12KT HVM



Input Voltage
60~145VDC



Output Voltage
154~272VAC



Output Current
40A-100A



Output Frequency
50/60 Hz(45~55Hz/55-65 Hz)



Size
360/540/218mm



Certificate
CE, IEC,TUV



Warranty
5 years



Weight
45kg



Product name
Growatt 4kw single phase SPF 4KT HVM off grid storage inverter



Waveform
Pure sine wave/ same as input(bypass mode)



Inverter Efficiency(Peak)
>88%



Transfer Time
10ms typical,20ms Max



Voltage
230VAC



<div class="attribute-item" style="border: 1px solid #dddddd; --tw-border-spacing-x: 0; --tw-border-spacing-y: 0; --tw-translate-x: 0; --tw-translate-y: 0; --tw-rotate: 0; --tw-skew-x: 0; --tw-skew-y: 0; --tw-scale-x: 1; --tw-scale-y: 1; --tw-scroll-snap-strictness: proximity; --tw-ring-offset-width: 0px; --tw-ring-offset-color: #fff; --tw-ring-color: rgba(59,130,246,.5); --tw-ring-offset-shadow: 0 0 #0000; --tw-ring-shadow: 0 0 #0000; --tw-shadow: 0 0 #0000; --tw-shadow-colored: 0 0 #0000; margin: 0px; padding: 0px; font-variant-numeric: inherit; font-variant-east-asian: inherit; font-variant-alternates: inherit; font-variant-position: inherit; font-stretch: inherit; line-height: inherit; font-family: Inter, 'SF Pro Text', Roboto, 'Helvetica Neue', Helvetica, Tahoma, Arial, 'PingFang SC', 'Microsoft YaHei'; font-optical-sizi

Datasheet
SPF 4KT HVM
SPF 5KT HVM
SPF 6KT HVM
SPF 8KT HVM
SPF 10KT HVM
SPF 12KT HVM
Battery Voltage
48VDC
Battery Type
Lithium/Lead-acid
INVERTER OUTPUT
Rated Power
4KW
5KW
6KW
8KW
10KW
12KW
Surge Rating
12KW
15KW
18KW
24KW
30KW
36KW
Waveform
Pure sine wave/ same as input(bypass mode)
Nominal Output Voltage RMS
220V/230V/240VAC(+/-10% RMS)
Output Frequency
50Hz/60Hz +/-0.3 Hz
Inverter Efficiency(Peak)
>85%
>88%
Line Mode Efficiency
>95%
Power Factor
1.0
Transfer Time
10ms typical,20ms Max
SOLAR CHARGER
Maximum PV Charge Current
80A
120A
Maximum PV Array Power
5000W
7000W
Number of independent MPP trackers/
strings per MPP tracker
1/1
2/1
MPPT Range @ Operating Voltage
60~145VDC
Maximum PV Array Open Circuit Voltage
150VDC
Maximum Efficiency
>98%
AC INPUT
Voltage
230VAC
Selectable Voltage Range
154~272VAC(for appliances);184~272VAC(for UPS)
Frequency Range
50Hz/60Hz (Auto sensing)
Maximum Charge Current
40A
50A
60A
80A
100A
120A
MECHANICAL SPECIFICATIONS
Protection Degree
IP20
Dimensions (W/H/D)
360/540/218mm
380/650/255mm
Net Weight (Solar CHG) kg
38
41
45
64
66
75
OPERATING ENVIRONMENT
Operation Temperature Range
0°C to 45°C



packing
