Sofar Three Phase 25KW On-grid Power Inverters Solar inverters for Residential

Place of Origin
Anhui, China



Brand Name
Sofar



Model Number
SOFAR 25KTLX-G3



Input Voltage
1100V



Output Voltage
310Vac-480Vac



Output Frequency
50/60Hz



Size
520*430*189



Certificate
CE/IEC



Warranty
10 Years



Weight
36kg

Datasheet

Model
25KTLX-G3
Input (DC)
Max. input voltage
1100V
Rated input voltage
620V
Start-up voltage
200V
MPPT operating voltage range
180V~1000V
Number of MPP trackers
3
Number of DC inputs
2 for each MPPT
May input MPPT current
3*40A
Max. input short circuit current
3*50A
Output (AC)
Rated output power
25000W
Max. apparent power
28000VA
Max. output current
42.4A
Pated output yoltage
3/N/PE, 230/400Vac
Output voltage range
310Vac-480Vac
Rated output frequency
50/60Hz
Output frequency range
45Hz-55Hz/55Hz-65Hz
Active power adjustable range
0~100%
THDi
<3%
Power factor
1 (adjustable +/-0.8)
Efficiency
Max. efficiency
98.6%
European efficiency
98.2%
General Data
Ambient temperature range
-30℃~+60℃
Self-consumption at night
<3W
Topology
Transformerless
Degree of protection
IP65
Allowable relative humidity range
0~100%
Max.operating altitude
4000m
Cooling
Smart air cooling
Dimension (W×H×D)
585×480×220mm
Weight
36kg
Display
LCD & Bluetooth +APP
Communication
RS485/WiFi
Standard
IEC/EN 61000-6-1/2/3/4,
IEC 62116, IEC 61727, IEC 61683, IEC 60068-1/2/14/30, IEC/EN 62109-1/2
G99, VDE-AR-N 4105, VDE V 0126-1-1,CEI0-21, EN 50549-1, NRS 097-2-1,UNE 217002-2020
